Detail produk:
|
| Bahan: | baja karbon dan stainless steel | Collor: | Minyak ringan |
|---|---|---|---|
| Ketebalan: | SGP | Standar: | JIS 2311 |
| Cahaya Tinggi: | JIS 2311 SGP Baja Karbon Siku,Fitting Pipa Dilas Mulus 45 Derajat,MINYAK CAHAYA 180 Derajat Siku |
||
1) Standar: JIS 2311
2) Bahan: A234- ST 37 SS400
3) OD: 1/2" - 48".
4) BB:SGP
5) Permukaan: Dicat dengan cat hitam (atau pernis), galvanis,Minyak ringan
6) Kemasan: kotak kayu, palet.
7) Pemeriksaan: uji tekanan air, pemeriksaan sinar-X
JIS-B2311-B2312-SGP-ELBOW-BEND-DRAWING
| Nominal | OD | Pusat ke Akhir | 90 Berat | 45 °Berat | ||||
| (NPS) | 90˚(F) | 45˚(H) | KG/PC | KG/PC | ||||
| SEBUAH | B | D | Panjang | Tembakan | Panjang | Panjang | Pendek | PANJANG |
| 15 | ½ | 21.7 | 38.1 | - | 15.8 | 0,08 | 0,05 | 0,04 |
| 20 | ¾ | 27.2 | 38.1 | - | 15.8 | 0.1 | 0,07 | 0,05 |
| 25 | 1 | 34 | 38.1 | 25.4 | 15.8 | 0.15 | 0.1 | 0,08 |
| 32 | 1¼ | 42,7 | 47.6 | 31.8 | 19.7 | 0,26 | 0.17 | 0.13 |
| 40 | 1½ | 48.6 | 57.2 | 38.1 | 23.7 | 0.35 | 0.24 | 0.18 |
| 50 | 2 | 60.5 | 76.2 | 50.8 | 31.6 | 0,64 | 0,43 | 0.32 |
| 65 | 2 | 76.3 | 95.3 | 63.5 | 39.5 | 1.12 | 0,75 | 0,56 |
| 80 | 3 | 89.1 | 114.3 | 76.2 | 47.3 | 1.58 | 1.05 | 0,79 |
| 90 | 3½ | 101.6 | 133.4 | 88.9 | 55.3 | 2.17 | 1.45 | 1.09 |
| 100 | 4 | 114.3 | 152.4 | 101.6 | 63.1 | 2.91 | 1.94 | 1.46 |
| 125 | 5 | 139.8 | 190.5 | 127 | 78.9 | 4.49 | 2.99 | 2.25 |
| 150 | 6 | 165.2 | 228.6 | 152.4 | 94.7 | 7.09 | 4.73 | 3.55 |
| 200 | 8 | 216.3 | 304.8 | 203.2 | 126.3 | 14.4 | 9.61 | 7.2 |
| 250 | 10 | 267.4 | 381 | 254 | 157.8 | 25.4 | 16.9 | 12,7 |
| 300 | 12 | 318.5 | 457.2 | 304.8 | 189,4 | 38.1 | 25.4 | 19.05 |
| 350 | 14 | 355.6 | 533.4 | 355.6 | 220.9 | 56,7 | 37.8 | 28.35 |
| 400 | 16 | 406.4 | 609.6 | 406.4 | 252,5 | 74.3 | 49.5 | 37.15 |
| 450 | 18 | 457.2 | 685.8 | 457.2 | 284.1 | 94.2 | 62.8 | 47.1 |
| 500 | 20 | 508 | 762 | 508 | 315.6 | 116 | 77.7 | 58 |
| 550 | 22 | 558.8 | 838.2 | 558.8 | 347.2 | 141 | 94.1 | 70.5 |
| 600 | 24 | 609.6 | 914.4 | 609.6 | 378.7 | 168 | 112 | 84 |
| 650 | 26 | 660,4 | 990.6 | 660,4 | 410.3 | 198 | 132 | 99 |
| 700 | 28 | 711.2 | 1066.8 | 711.2 | 441.9 | 230 | 154 | 115 |
| 750 | 30 | 762 | 1143 | 762 | 473.4 | 264 | 176 | 132 |
| 800 | 32 | 812.8 | 1219.2 | 812.8 | 505 | 301 | 201 | 150.5 |
| 850 | 34 | 863.6 | 1295.4 | 863.6 | 536.6 | 340 | 227 | 170 |
| 900 | 36 | 914.4 | 1371.6 | 914.4 | 568.1 | 380 | 253 | 190 |
| 950 | 38 | 965.2 | 1447.8 | 965.2 | 599.7 | 425 | 283 | 212.5 |
| 1000 | 40 | 1016 | 1524 | 1016 | 631.2 | 471 | 314 | 235.5 |
| 1050 | 42 | 1066.8 | 1600.2 | 1066.8 | 662.8 | 518 | 346 | 259 |
| 1100 | 44 | 1117,6 | 1676,4 | 1117,6 | 694.4 | 570 | 380 | 285 |
| 1150 | 46 | 1168.4 | 1752.6 | 1168.4 | 725.9 | 623 | 415 | 311.5 |
| 1200 | 48 | 1219.2 | 1828.8 | 1219.2 | 757,5 | 677 | 452 | 338.5 |
| Nominal | OD | C ke C | Ujung ke ujung | 180 Berat | ||||
| (NPS) | 180˚ (P) | 180˚(K) | KG/PC | |||||
| SEBUAH | B | D | Panjang | Tembakan | Panjang | Tembakan | Panjang | Pendek |
| 15 | ½ | 21.7 | 76.2 | - | 49 | - | 0.16 | 0.1 |
| 20 | ¾ | 27.2 | 76.2 | - | 51.7 | - | 0.2 | 0.14 |
| 25 | 1 | 34 | 76.2 | 50.8 | 55.1 | 42.4 | 0,3 | 0.2 |
| 32 | 1¼ | 42,7 | 95.2 | 63.6 | 69 | 53.2 | 0,52 | 0.34 |
| 40 | 1½ | 48.6 | 114.4 | 76.2 | 81.5 | 62.4 | 0,7 | 0,48 |
| 50 | 2 | 60.5 | 152.4 | 101.6 | 106,5 | 81.1 | 1.28 | 0,86 |
| 65 | 2 | 76.3 | 190.6 | 127 | 133.5 | 101.7 | 2.24 | 1.5 |
| 80 | 3 | 89.1 | 228.6 | 152.4 | 158.9 | 120.8 | 3.16 | 2.1 |
| 90 | 3½ | 101.6 | 266.8 | 177.8 | 184.2 | 139.7 | 4.34 | 2.9 |
| 100 | 4 | 114.3 | 304.8 | 203.2 | 209.6 | 158.8 | 5.82 | 3.88 |
| 125 | 5 | 139.8 | 381 | 254 | 260.4 | 196.9 | 8.98 | 5.98 |
| 150 | 6 | 165.2 | 457.2 | 304.8 | 311.2 | 235 | 14.18 | 9.46 |
| 200 | 8 | 216.3 | 609.6 | 406.4 | 413 | 311.4 | 28.8 | 19.22 |
| 250 | 10 | 267.4 | 762 | 508 | 514.7 | 387.7 | 50.8 | 33.8 |
| 300 | 12 | 318.5 | 914.4 | 609.6 | 616,5 | 464.1 | 76.2 | 50.8 |
| 350 | 14 | 355.6 | 1066.8 | 711.2 | 711.2 | 533.4 | 113.4 | 75.6 |
| 400 | 16 | 406.4 | 1219.2 | 812.8 | 812.8 | 609.6 | 148.6 | 99 |
| 450 | 18 | 457.2 | - | - | - | - | 188.4 | 125.6 |
| 500 | 20 | 508 | - | - | - | - | 232 | 155.4 |
| 550 | 22 | 558.8 | - | - | - | - | 282 | 188.2 |
| 600 | 24 | 609.6 | - | - | - | - | 336 | 224 |
| 650 | 26 | 660,4 | - | - | - | - | 396 | 264 |
| 700 | 28 | 711.2 | - | - | - | - | 460 | 308 |
| 750 | 30 | 762 | - | - | - | - | 528 | 352 |
| 800 | 32 | 812.8 | - | - | - | - | 602 | 402 |
| 850 | 34 | 863.6 | - | - | - | - | 680 | 454 |
| 900 | 36 | 914.4 | - | - | - | - | 760 | 506 |
| 950 | 38 | 965.2 | - | - | - | - | 850 | 566 |
| 1000 | 40 | 1016 | - | - | - | - | 942 | 628 |
| 1050 | 42 | 1066.8 | - | - | - | - | 1036 | 692 |
| 1100 | 44 | 1117,6 | - | - | - | - | 1140 | 760 |
| 1150 | 46 | 1168.4 | - | - | - | - | 1246 | 830 |
| 1200 | 48 | 1219.2 | - | - | - | - | 1354 | 904 |
Bahan
1) Baja Karbon, S235 & Baja Tahan Karat SS304, SS316, SS316L
Permukaan Antirust:
Permukaan antirust 1: Minyak ringan antirust
Permukaan antirust 2: Lapisan cat hitam
Permukaan antirust 3: Galnavis (Hot Dipped Galvanized atau Electro Galvanized
Syarat:
1) Pembayaran: L/C yang tidak dapat dibatalkan pada pandangan atau T/T, D/P
2) Istilah pengiriman FOB China Port atau CIF Buyer's Port
3) Pengepakan: Pallet / kasing kayu lapis
Kontak:
Manajer Penjualan: Grace Zhang
HEBEI XINFENG TEKANAN TINGGI FLANGE DAN PIPA FITTING CO.,LTD.
Tambahkan.: Kabupaten Mencun, Kota Cangzhou, provinsi Hebei, Cina 061400
Ponsel: 86 18031772015 (wechat, whatsapp)
Telp: 86-317-6725755
Surel: info4@hbxfgj.com
Skype: cangzhouzhangnan
FAQ:
1. Apa MOQ Anda?
Biasanya MOQ kami untuk setiap ukuran adalah 1ton.Jika Anda pikir itu terlalu banyak, kita bisa mendiskusikan sesuai dengan kebutuhan Anda secara rinci.
2. Dapatkah Anda menawarkan sampel gratis?
Ya, kami dapat menyediakan sampel gratis 150m - 200m.
3. Apa waktu pengiriman Anda?
Kami akan mengirimkan dalam 30-45 hari
4. Dapatkah Anda menerima produk campuran dalam satu wadah?
Ya, kami menerima dengan pasti.
