Detail produk:
|
| Baja karbon: | ,S235JRG2,P245GH ,P250GH,A105,SS400,SF440 | SS BAJA: | F304 F304L F316 F316L |
|---|---|---|---|
| Ukuran: | NB 1/2" SAMPAI NB 48". | Tekanan: | PN6 PN10 PN16 PN25 PN40 |
| Perawatan Permukaan: | Minyak Anti Karat, Cat Anti Karat Transparan/Kuning/Hitam, Seng, Galvanis Dicelup Panas | Pengemasan: | Tidak Ada Fumigasi atau Fumigasi Kayu Lapis/Palet atau Kasing Kayu |
| Penggunaan: | Ladang Minyak, Lepas Pantai, Sistem Air, Pembuatan Kapal, Gas Alam, Tenaga Listrik, Proyek Pipa, dll | ||
| Cahaya Tinggi: | pn16 flensa wajah datar,flensa tempa baja karbon wajah datar,flensa tempa baja karbon en1092 |
||
| Standar | ANSI | ANSI B16.5 ASME B16.47 seri A/B |
| KERIUHAN | DIN 2631 2573 2527 2565 2641 | |
| GOST | GOST 12820-80,GOST 12821-80,Gost Buta | |
| EN | EN1092-1:2002 | |
| JIS | JIS B2220-2004, KS D3576, KS B6216, KS B1511-2007, JIS B2261;JIS B8210 | |
| BS | BS4504,BS10 Tabel D/E | |
| UNI | UNI 2253-67,UNI6091-67,UNI2276-67,UNI2280-67,UNI6089-67 | |
| SABS | SAB 1123 | |
| ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 ,JIS,DIN,BS4504,SABS1123,EN1092-1, UNI,AS2129,GOST-12820 DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636 , DIN2637, DIN2638, DIN2673 BS : BS4504 , BS4504, BS1560, BS10 |
||
| Bahan | ANSI | CS A105/SA 105N,SS 304/304L,316/316L |
| KERIUHAN | CS RST37.2;S235JR SS 304/304L,316/316L | |
| GOST | CS CT20;16MN;SS 304/304L,316/316L | |
| EN | CS RST37.2;S235JR;C22.8SS 304/304L,316/316L | |
| JIS | CS SS400,SF440,SS 304/304L, 316/316L | |
| BS | CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L | |
| UNI | CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L | |
| SABS | CSRST37.2;S235JR;Q235;SS 304/304L,316/316L | |
| Flensa Tempa Stainless Steel: ASTM A182F304,304L,316,316L Flensa Tempa Baja Karbon: ,S235JRG2,P245GH ,P250GH,A105,SS400,SF440 |
||
| Tekanan | ANSI | Kelas 150, 300, 600, 900, 1500, 2500 |
| KERIUHAN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| GOST | PN6,PN10,PN16,PN25 | |
| EN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| JIS | 1K,2K,5K,10K,16K,20K,30K,40K | |
| BS | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| UNI | PN6,PN10,PN16,PN25,PN40 | |
| SABS | 600KPA,1000,1600,2500,4000 | |
| Ukuran | ANSI | 1/2” – 60” |
| KERIUHAN | DN15-DN2000 | |
| GOST | DN10-DN1600 | |
| EN | DN15-DN2000 | |
| JIS | 15A-1500A | |
| BS | DN15-DN2000 | |
| UNI | DN10-DN2000 | |
| SABS | DN10-DN1200 | |
| Lapisan | Cat Hitam, Cat Kuning, Minyak anti karat, Galvanisasi dll | |
| Penggunaan | Digunakan untuk koneksi semua jenis pipa | |
| untuk menyampaikan air, uap, udara, gas dan minyak | ||
| Kemasan | Kotak/palet kayu | |
| Pengiriman | Dalam 30 hari | |
| Sertifikat | TUV, ISO9001 | |
| Kelas Tekanan | Kelas 150, Kelas 300, Kelas 400, Kelas 600, Kelas 900, Kelas 1500, Kelas 2500 |PN6, PN10, PN16, PN25, PN40, PN64 dll Sesuai gambar | |
| Mengkhususkan |
||
